型 號 Item No. |
螺栓規格 | 螺栓直徑 | 尺寸 DIMENSION（mm） | ||
| USA screw | D2 | W | F | L | |
| R1.25-3連帶 | #4 | 3.2 | 5.7 | 4.95 | 12.6 |
| RS1.25-3.5連帶 | #6 | 3.7 | 5.7 | 4.95 | 12.6 |
| RM1.25-3.5連帶 | #6 | 3.7 | 6.6 | 6.3 | 14.4 |
| RL1.25-3.5連帶 | #6 | 3.7 | 8.0 | 7 | 15.8 |
| RS1.25-4連帶 | #8 | 4.3 | 6.6 | 6.3 | 14.4 |
| RL1.25-4連帶 | #8 | 4.3 | 8.0 | 7 | 15.8 |
| RS1.25-5連帶 | #10 | 5.3 | 8.0 | 7 | 15.8 |
| RL1 25-5連帶 | #10 | 5.3 | 9.8 | 8.5 | 18 |
| RS1.25-6連帶 | 1/4 | 6.4 | 9.8 | 8.5 | 18 |
| RL1.25-6連帶 | 1/4 | 6.4 | 11.6 | 11.1 | 21.8 |
| R1.25-8連帶 | 5/16 | 8.4 | 11.6 | 11.1 | 21.8 |
| R1.25-10連帶 | 3/18 | 10.5 | 13.6 | 13.9 | 25.5 |
| R2-3連帶 | #4 | 3.2 | 6.6 | 4.3 | 12.3 |
| RS2-3.5連帶 | #6 | 3.7 | 6.6 | 4.3 | 12.3 |
| RM2-3.5連帶 | #6 | 3.7 | 6.6 | 7 | 16 |
| RL2-3.5連帶 | #6 | 3.7 | 8.5 | 7.75 | 16.8 |
| RS2-4連帶 | #8 | 4.3 | 6.6 | 7 | 16 |
| RL2-4連帶 | #8 | 4.3 | 8.5 | 7.75 | 16.8 |
| RS2-5連帶 | #10 | 5.3 | 8.5 | 7.75 | 16.8 |
| RL2-5連帶 | #10 | 5.3 | 9.5 | 7.25 | 16.8 |
| RL2-6連帶 | 1/4 | 6.4 | 12.0 | 11 | 21.8 |
| R2-8連帶 | 5/16 | 8.4 | 12.0 | 11 | 21.8 |
| R2-10連帶 | 3.18 | 10.5 | 14.6 | 13.9 | 26 |
| R3.5-4連帶 | #8 | 4.3 | 8.0 | 7.7 | 18 |
| RS3.5-5連帶 | #10 | 5.3 | 8.0 | 7.7 | 18 |
| RL3.5-5連帶 | #10 | 5.3 | 12.0 | 7.7 | 21.4 |
| R3.5-6連帶 | 1/4 | 6.4 | 12.0 | 7.7 | 21.4 |
| R3.5-8連帶 | 5/16 | 8.4 | 15.0 | 14 | 27.5 |
| R3.5-10連帶 | 3/18 | 10.5 | 15.0 | 14 | 27.5 |
| R5.5-3.5連帶 | #6 | 3.7 | 7.2 | 5.9 | 15.7 |
| RS5.5-4連帶 | #8 | 4.3 | 7.2 | 8.3 | 19.8 |
| RL5.5-4連帶 | #8 | 4.3 | 9.5 | 8.3 | 19.8 |
| R5.5-5連帶 | #10 | 5.3 | 9.5 | 13 | 25.8 |
| R5.5-6連帶 | 1/4 | 6.4 | 12.0 | 13.7 | 28.0 |
| R5.5-8連帶 | 5/16 | 8.4 | 15.0 | 13.7 | 28.0 |
| R5.5-10連帶 | 3/18 | 10.5 | 15.0 | 16 | 32.4 |
